Description
The Makita HS7601 Circular Saw is a compact and lightweight tool giving 1200 watts of continuous input. This model succeeds the popular 5704R and has a number of improvements and refinements (EG lighter and more compact)
Features:
- Double Insulationhttps
- Compact and lightweight design
- New aesthetic design
- Compatible with Guide Rail
- Rear dust exhaust port
- Connectable to dust extractor
- Rear angular guide for smooth and precise adjustment of bevel angle
- Single action lever for quick adjustment of cutting depth
- Ergonomic soft grip for extra comfort
- Flat motor housing end making the tool more stable when changing blades
- Aluminium die-cast safety cover
- Aluminium base plate
- Depth of Cut @ 90°: 66 mm
Blade Diameter: 190 mm
Depth of Cut @ 45º: 46 mm
Bore Diameter: 30 mm
Noise sound pressure: 87 dB(A)
Noise sound power: 98 dB(A)
Noise K factor: 3 dB(A)
Input Wattage: 1200 w
No Load Speed: 5200 rpm
Vibration K factor: 1.5 m/sec²
Vibration: Cutting Wood: 2.5 m/sec²
Overall length: 309 mm
Net weight: 4.0 kg
Total Shipping Weight: 7kg
